YG BulletShield™ Series
Bullet-Resistant Acrylic
High-clarity protective material tested under CNS 14998 IIA ballistic standards
- Thickness 14.5 mm
- CNS 14998 (2006) IIA
- NIJ 0108.01 IIA
- High-molecular-weight cast PMMA
The Yng Guang BulletShield™ acrylic panel is manufactured using high-molecular-weight cast PMMA.
At a thickness of 14.5 mm, it has successfully passed the CNS 14998 (2006) Type IIA .357 Magnum JSP ballistic test, equivalent to the NIJ 0108.01 IIA protection level.
At a thickness of 14.5 mm, it has successfully passed the CNS 14998 (2006) Type IIA .357 Magnum JSP ballistic test, equivalent to the NIJ 0108.01 IIA protection level.
Unlike conventional multi-layer bullet-resistant glass or laminated polycarbonate sheets,
YG BulletShield™ combines effective ballistic protection with high optical transparency (≈92%), lightweight design, and excellent workability.
It is ideal for bank teller counters, security windows, vehicle partitions, and display enclosures where both protection and visual clarity are essential.
*Ballistic performance may vary depending on bullet type, velocity, angle, temperature, and installation method. For critical applications, on-site verification and third-party testing are strongly recommended.
Key Features
- 🛡️ Certified Ballistic Protection
Reliable safety verified through live-fire testing: rigorously tested under CNS 14998 (2006) IIA with .357 Magnum JSP rounds, and compliant with
NIJ 0108.01 IIA ballistic standards. - 💎 Exceptional Optical Clarity
True visual transparency without distortion: features outstanding optical quality with 92% light transmittance (ASTM D1003 certified), ensuring both protection and clear visibility. - ⚖️ Lightweight & Easy Installation
Structural efficiency and cost optimization: with a density of only 1.19 g/cm³, it is significantly lighter than traditional bulletproof glass,
reducing structural load, simplifying installation, and cutting project costs. - ☀️ Weather-Resistant Durability
Long-lasting outdoor performance: formulated with specialized UV-stabilizers and anti-oxidation additives to maintain clarity and strength even after prolonged exposure, extending service life and reliability. - 🧪 Superior Chemical Resistance
Built for durability and ease of maintenance: in addition to its strength and weatherability, the material resists chemical attack and supports diverse machining and cleaning applications in demanding environments.
Glass vs. PC vs. Acrylic
Striking the perfect balance among clarity × weight × ballistic strength,the YG BulletShield™ bulletproof acrylic panel offers a superior alternative to both glass and polycarbonate.
| Property | YG Bulletproof Acrylic Panel | Bulletproof Glass | Bulletproof PC (Polycarbonate) |
|---|---|---|---|
| Transparency | ★★★★★ (≈92%, colorless, no tint) | ★★★★ (≈85–88%, slight green hue) | ★★★ (≈80–86%, bluish/yellowish tone) |
| Weight | ~50% lighter than glass, easy to install | Heavy; high structural load | Lighter but prone to heat deformation |
| Scratch Resistance / Surface Hardness | ★★★★ (high hardness cast surface) | ★★★★★ (excellent) | ★★ (soft surface, requires hard coating) |
| Ballistic Rating | IIA (single 14.5 mm layer) | III–IV (multi-layer laminated18~20mm) | IIA–III-A (multi-layer composite15mm) |
| Fabrication | Easy (CNC cutting, thermoforming, bonding) | Difficult | Heat forming causes whitening; limited adhesion |
| Weatherability | Excellent (anti-yellowing formulation) | Excellent | Poor (aging and yellowing over time) |
| Price Range | Medium (high cost-performance ratio) | High | Medium-high |
Conclusion:
Bulletproof glass is heavy, and bulletproof PC tends to yellow over time — the YG BulletShield™ bulletproof acrylic panel combines clarity, aesthetics, protection, and design flexibility in one solution.
